Power Distribution Panels
LT Distribution Panel
Floor-standing and wall-mounted distribution panels and distribution boards (DBs) that feed power from the main LT panel to floors, sections and equipment.
- Feeders
- MCCB or MCB, as per BOQ
- Mounting
- Floor-standing or wall-mounted
- Operating voltage
- 380 / 415 / 440 V AC, 3-phase, 4-wire
- Frequency
- 50 Hz
Overview
Distribution panels take power from the main LT panel and divide it among floors, sections of a plant or individual items of equipment, protecting each outgoing circuit with MCCBs or MCBs.
We build indoor and outdoor distribution panels and distribution boards (DBs) to your BOQ, from compact boards to multi-section panels with metering on the incomer.
Key features
- MCCB or MCB outgoing feeders, as per your BOQ
- Aluminium TPN busbars rated to the load
- Incomer metering: ammeter, voltmeter or multifunction meter
- Floor-standing or wall-mounted, indoor or outdoor
- Powder coated up to 100 microns over 7-tank pre-treatment
Technical specifications
| Parameter | Value |
|---|---|
| Feeders | MCCB or MCB, as per BOQ |
| Mounting | Floor-standing or wall-mounted |
| Operating voltage | 380 / 415 / 440 V AC, 3-phase, 4-wire |
| Frequency | 50 Hz |
| Short-circuit rating | Up to 50 kA for 1 s (CPRI-tested); higher on request |
| Degree of protection | Up to IP55 (CPRI-tested) |
| Internal separation | Up to Form 4 |
| Sheet steel | CRCA, 2 mm or 1.6 mm as specified |
| Surface finish | 7-tank pre-treatment, powder coated up to 100 microns |
| Busbars | Aluminium, TPN, rated to the load |
| Standard | IS/IEC 61439-1 and 61439-2 |
Applications
- Commercial and office buildings
- Residential societies
- Factories and workshops
- Hospitals
- Schools and institutions
Example builds
Indoor distribution panel
400 A TPN aluminium busbar, 2 mm CRCA, powder coated up to 100 microns
FAQs
Related panels
Meter Board Panel
Wall-mounted meter boards that house energy meters and their protection for individual consumers in residential and commercial buildings.
Feeder Pillar
Indoor and outdoor feeder pillars that distribute power across campuses, townships and street-lighting networks from one compact enclosure.
Have a BOQ or single-line diagram?
Send it today for an itemised quote on your panels.
